| Cadre | Aluminium : 2022 Meta TR, 140 mm travel, 29 », Alloy 6066, triple butted tubes, T4, T6. Enduro bearings |
| Fourche | Rockshox Revelation RC 150 mm travel, 29″, Motion Control RC damper, rebound, Boost (15 x 110 mm), 42 mm offset, 1 Token |
| Amortisseur | Rockshox Deluxe Select+ 210 x 55 mm, rebound, threshold adjustment, 2 tokens |
| Manette de dérailleur | Sram SX Eagle 1×12 vitesses |
| Dérailleur arrière | Sram SX Eagle 12 vitesses |
| Cassette | Sram PG-1210 11-50 Dents |
| Pédalier | Sram X1 1000 Eagle, 170 mm, DUB, Boost / Chainring: SRAM X1 1000 Eagle, 32t, Narrow-Wide |
| Boîtier de pédalier | Sram DUB |
| Freins | Sram Guide T, 4 pistons, matchmaker compatible / Rotor: Sram G2 CleanSweep 200 mm, 6-bolt |
| Roues | E13 LG1 EN Base 29″, 32h, 30 mm inner width |
| Pneus | F : Maxxis DHR II 29″ x 2.40″, WT, EXO, dual compound, Tubeless Ready / R : Maxxis Dissector 29″ x 2.40″, WT, EXO, dual compound, Tubeless Ready |
| Guidon | Ride Alpha R20 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S – 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L – 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL |
| Potence | Ride Alpha Freeride 40 mm extension, 31,8 mm |
| Jeu de direction | ACROS ZS44/ZS56 |
| Selle | SDG Bel Air V3 |
| Tige de selle | KS Rage-I 34.9 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote |
| Poids | 15 kg |
| Coloris | Dirt |
| Taille de cadre | S | M | L | XL |
| Tube de selle (mm) | 380 | 418 | 440 | 465 |
| Tube supérieur (mm) | 565 | 591 | 617 | 643 |
| Longueur base (mm) | 434 | 434 | 434 | 434 |
| Douille de direction (mm) | 110 | 115 | 120 | 125 |
| Angle de direction (°) | 65 | 65 | 65 | 65 |
| Angle tube de selle (°) | 79 | 79 | 79 | 79 |
| Empattement (mm) | 1202 | 1229 | 1256 | 1283 |
| Stack (mm) | 623 | 627 | 631 | 635 |
| Reach (mm) | 444 | 469 | 494 | 519 |
