| Cadre | Aluminium : 2022 Clash, 170 mm, 27.5 », Alloy 6066, triple butted tubes, T4, T6. Enduro bearings |
| Fourche | Rockshox Zeb, 180 mm, 27.5″, Charger damper, Debonair, rebound, Boost (15 x 110 mm), 38 mm offset, 0 Token |
| Amortisseur | Rockshox Super Deluxe Select, 230 x 65 mm, rebound, 3 Tokens |
| Manette de dérailleur | Sram SX Eagle 1×12 vitesses |
| Dérailleur arrière | Sram SX Eagle 12 vitesses |
| Cassette | Sram PG-1210 11-50 Dents |
| Pédalier | Sram X1 1000 Eagle, 170 mm, DUB, Boost / Chainring: SRAM X1 1000 Eagle, 34t, Narrow-Wide |
| Boîtier de pédalier | Sram DUB |
| Freins | Sram Guide T, 4 pistons, matchmaker compatible / Rotor: Sram G2 CleanSweep 200 mm, 6-bolt |
| Roues | E13 LG1 DH Base 27.5 », 32h, 30 mm inner width |
| Pneus | F : Maxxis Assegai 27.5″ x 2.5″, WT, 3C MaxxGrip, EXO+, Tubeless Ready / R : Maxxis DHR II 27.5″ x 2.4″, WT, 3C MaxxTerra, EXO+, Tubeless Read |
| Guidon | Ride Alpha R20 760 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S – 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L – 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL |
| Potence | Ride Alpha Freeride 40 mm extension, 31.8 mm |
| Jeu de direction | ACROS ZS44/ZS56 |
| Selle | SDG Bel Air V3 |
| Tige de selle | KS Rage-I 34.9 mm, travel: 125 mm on S, 150 mm on M, 170 mm on L, 190 mm on XL, SouthPaw alloy remote |
| Poids | 16.1 kg |
| Coloris | Dirt |
| Taille de cadre | S | M | L | XL |
| Tube de selle (mm) | 380 | 418 | 440 | 465 |
| Tube supérieur (mm) | 586 | 607 | 633 | 666 |
| Longueur base (mm) | 434 | 434 | 434 | 434 |
| Douille de direction (mm) | 110 | 115 | 120 | 125 |
| Angle de direction (°) | 64 | 64 | 64 | 64 |
| Angle tube de selle (°) | 77.2 | 77.2 | 77.2 | 77.2 |
| Empattement (mm) | 1216 | 1238 | 1265 | 1292 |
| Stack (mm) | 619 | 624 | 628 | 635 |
| Reach (mm) | 445 | 465 | 490 | 520 |
