| Cadre | Aluminium : 2022 Clash, 170 mm, 27.5 », Alloy 6066, triple butted tubes, T4, T6. Enduro bearings |
| Fourche | Fox 38 Factory, 180 mm travel, 27.5″, Grip 2 damper, HSC, LSC, HSR, LSR, Boost (15 x 110 mm), 37 mm offset, 1 Token |
| Amortisseur | Fox DHX2 Factory, 230 x 65 mm, HSC, LSC, HSR, LSR. Spring rates : 400lbs on S, 450lbs on M, 500lbs on L, 550lbs on XL, 2-position adjustment |
| Manette de dérailleur | Sram GX DH 1×7 vitesses |
| Dérailleur arrière | Sram GX DH, 7 vitesses |
| Cassette | Sram GX DH, 11-25 Dents |
| Pédalier | Truvativ Descendant, 165 mm crank arms, DUB / Chainring: Truvativ Descendant X-Sync, 32 dents |
| Chaîne | KMC X11EL |
| Guide-Chaîne | E13 TRS, 30-32 dents |
| Boîtier de pédalier | Sram DUB, PressFit, BB92 |
| Freins | Shimano XT, 4 pistons, I-Spec EV Compatible, Rotor: Shimano SM-RT86 203/203 mm, 6-bolt, Ice Technology Freeza |
| Roues | Spank Spike Race 33 27.5 », 32h, 28 mm inner width, Tubeless Ready / Moyeux Spank Spike Rear: HEX J-Type, 32h, 2 sealed bearings, 12 x 148 mm, HG, black – Front: HEX J-Type, 32h, 2 sealed bearings, 15 x 110 mm, black |
| Pneus | F : Maxxis Assegai 27.5″ x 2.5″, WT, 3C MaxxGrip, EXO+, Tubeless Ready / R : Maxxis DHR II 27.5″ x 2.4″, WT, 3C MaxxTerra, EXO+, Tubeless Ready |
| Guidon | Title AH1 35, 35 mm, 810 mm width, 20 mm rise, Alloy 7050 T74 |
| Poignées | ODI Elite Motion, Soft pro compound, single clamp, black |
| Potence | Title ST1 35, 40 mm extension, 35 mm, Alloy 6061 T6, oil slick stainless steel bolts |
| Jeu de direction | ACROS ZS44/ZS56 |
| Selle | SDG Patriot I-Beam |
| Tige de selle | SDG Micro I-Beam, 31.6 mm, 250 mm length |
| Poids | 15.6 kg |
| Coloris | Metallic Purple |
| Taille de cadre | S | M | L | XL |
| Tube de selle (mm) | 380 | 418 | 440 | 465 |
| Tube supérieur (mm) | 586 | 607 | 633 | 666 |
| Longueur base (mm) | 434 | 434 | 434 | 434 |
| Douille de direction (mm) | 110 | 115 | 120 | 125 |
| Angle de direction (°) | 64 | 64 | 64 | 64.5 |
| Angle tube de selle (°) | 77.2 | 77.2 | 77.2 | 77.1 |
| Empattement (mm) | 1216 | 1238 | 1265 | 1292 |
| Stack (mm) | 619 | 624 | 628 | 635 |
| Reach (mm) | 445 | 465 | 490 | 520 |
