| Cadre | Aluminium : Meta HT AM 2022, Alloy 6061, triple butted (T4, T6), 148×12 mm Standard Maxle, Tire clearance: ETRTO 71-584 / 71 mm (Measured Width) |
| Fourche | RockShox 35 Gold RL, 150 mm travel, 29″, DebonAir, rebound, Boost (15×110 mm), 44 mm offset, 0 Token |
| Manette de dérailleur | Sram SX Eagle, 1×12-vitesses |
| Dérailleur arrière | Sram SX Eagle, 12-vitesses |
| Cassette | Sram PG-1210, 11-50 Dents |
| Chaîne | Sram NX Eagle |
| Pédalier | Sram X1 1000 Eagle, 170 mm crank arms, DUB, Boost, Sram X1 1000 Eagle, Narrow-Wide Chainring, 32 Dents |
| Boîtier de pédalier | Sram BSA, Threaded, 68 mm |
| Freins | Sram Level, Hydr. Disc Brake, 2-pistons, Sram G2 CleanSweep 200/180 mm, 6-bolt Rotors |
| Roues | Jantes : E13 LG1 EN Base, 29/29″ (29/27.5″ tailles S et M), 32h, 30 mm inner width / Rayons : Sapim Leader, J-Bend 2.0 mm, stainless, with Nylok, black |
| Moyeux | Avant : Formula DC-711, 32h, sealed bearings / Arrière : Formula DC-348A, 32h, sealed bearings |
| Pneus | Maxxis Dissector, EXO, Tubeless Ready, 29×2.6″ (29/27.5×2.6″ tailles S et M) |
| Guidon | Ride Alpha R27, 31.8 mm, 27 mm rise, Alloy 6061, 780 mm (M, L), 800 mm (XL) width / Ride Alpha R20, 31.8 mm, 20 mm rise, Alloy 6061, 760 mm width (S) |
| Potence | Ride Alpha Freeride, 31.8 mm, 40 mm extension |
| Jeu de direction | Acros ZS44/ZS56, Alloy cups, sealed bearings, Tapered 1-1/8″ / 1-1/2″ |
| Poignées | ODI Elite Motion, Soft pro compound, single clamp, black |
| Selle | SDG Bel Air V3, Steel rails |
| Tige de selle | Ride Alpha, 31.6 mm, 400 mm (S, M), 450 mm (L, XL) length |
| Poids | 14.2 kg (Average weight for S size, without pedals) |
| Coloris | Dirt – Matte Finish |
| Taille cadre | S | M | L | XL |
| Taille de roues (pouces) | 29 / 27.5 | 29 / 27.5 | 29 | 29 |
| Tube de selle (mm) | 380 | 420 | 465 | 490 |
| Tube supérieur (mm) | 582 | 604 | 630 | 655 |
| Longueur base (mm) | 432 | 432 | 432 | 432 |
| Douille de direction (mm) | 115 | 120 | 125 | 130 |
| Angle de direction (°) | 64 | 64 | 64.5 | 64.5 |
| Angle tube de selle (°) | 74 | 74.5 | 74.5 | 74.5 |
| Empattement (mm) | 1180 | 1202 | 1229 | 1232 |
| Stack (mm) | 638 | 643 | 647 | 643 |
| Reach (mm) | 405 | 425 | 450 | 475 |
