| Cadre | Aluminium : Alpenchallenge 01 Premium Alloy, Belt Drive, Triple-butted, Hydroformed Aluminium, Internal Cable Routing, Eccentric Bottom Bracket, 32 mm tire clearance |
| Fourche | Carbone : Alpenchallenge 01 Carbon, 45 mm offset |
| Manette de dérailleur | Shimano Alfine 8, Rapidfire Plus, 1×8-vitesses |
| Dérailleur arrière | Shimano Alfine 8, 8-vitesses, Intégré au moyeu |
| Cassette | Gates CDX-CT SureFit, 24 Dents, 8-vitesses |
| Courroie | Belt, Gates CDN-CT 115 |
| Pédalier | Gates CenterTrack CDN-S-150, 55 Dents |
| Freins | Shimano MT400, Hydr. Disc Brake, (160/160) RT30 Rotors |
| Roues | Jantes : SR500 / Moyeux : Shimano HB-M4050 / Shimano Alfine 8 |
| Pneus | Continental Contact Speed, 700×28 mm |
| Guidon | Lightskin with integrated lights, 620 mm, 9° backsweep |
| Potence | BMC MSM01, -5° |
| Selle | Selle Royal Vivo |
| Tige de selle | Lightskin with integrated lights |
| Poids | 11.5 kg |
| Coloris | Metallic Anthracite |
| Taille de cadre | S | M | L | XL |
| Tube de selle (mm) | 440 | 485 | 515 | 560 |
| Tube supérieur (mm) | 547 | 575 | 590 | 617 |
| Longueur base (mm) | 412 | 412 | 412 | 412 |
| Douille de direction (mm) | 100 | 140 | 160 | 200 |
| Angle de direction (°) | 72 | 72 | 72 | 72 |
| Angle tube de selle (°) | 73.5 | 73.5 | 73.5 | 73.5 |
| Empattement (mm) | 992 | 1022 | 1037 | 1075 |
| Stack (mm) | 533 | 571 | 590 | 628 |
| Reach (mm) | 390 | 406 | 415 | 431 |
| Longueur potence (mm) | 80 | 80 | 90 | 90 |
