| Cadre | Acier : Double Butted Chromoly Tubing, IS disc mount |
| Fourche | Acier : Chromoly, IS Disc Mount, 1″1/8 offset 45mm |
| Jeu de direction | 1-1/8 Alloy top cover, caged ball bearings |
| Manette de dérailleur | Sram Apex, 2×10 vitesses |
| Dérailleur avant | Sram Apex |
| Dérailleur arrière | Sram Apex, 10 vitesses |
| Cassette | Sram Apex, 11-32 Dents |
| Pédalier | FSA Vero Pro 46-30 175mm |
| Freins | Promax DSK300R Mech Disc, 160mm Rotor F/R |
| Roues | Fluide Alex DP23 700c tubless Ready, Alloy, Double wall, 32H |
| Moyeux | Fluide Alloy Black Loose |
| Pneus | Kenda Flintridge 700x400mm |
| Guidon | AL-6061, 31.8mm, FLARE 16°, DRP, 130mm, REACH : 86mm |
| Potence | 3D Forged Alloy 31.8mm ext 100mm |
| Selle | Fluide 1922 soft |
| Tige de selle | 3D Forged Alloy, 27.2mm |
| Poids | — |
| Coloris | Vert |
| Taille cadre | S | M | L | XL |
| Tube de selle (mm) | 510 | 535 | 560 | 580 |
| Tube supérieur (mm) | 530 | 535 | 555 | 575 |
| Longueur base (mm) | 432 | 432 | 432 | 432 |
| Douille de direction (mm) | 110 | 130 | 160 | 170 |
| Angle de direction (°) | 71.5 | 72 | 72 | 72 |
| Angle tube de selle (°) | 74 | 73.5 | 73 | 73 |
| Empattement (mm) | 1004 | 1006 | 1022 | 1042 |
